MILOS 8×6 m Stage
Technical Specifications
| Stage size | 8 × 6 m |
| Internal width | 8.16 m |
| Overall external width | 8.73 m |
| Internal depth | 5.44 m |
| Overall external depth | 6.03 m |
| Clearance | 3.95 m |
| Overall height | 4.95 m |
| Leg adjustment range | 572–950 mm |
| Front and rear truss loading | Up to 30 kg/m |
| Side truss loading | Up to 25 kg/m |
On OrderSKU: 03C722Сцени
The MILOS 8×6 m Stage is a professional aluminium staging structure designed for concerts, festivals, corporate events, presentations and other medium-sized events.
The key feature of the structure is the innovative Corner Brace HD system, which eliminates the need for guy wires. This reduces construction time, lowers ballast requirements and provides a clear area around all sides of the stage.
The structure is designed to support significant loads: up to 30 kg/m on the front and rear trusses, up to 25 kg/m on the side trusses and up to 10 kg/m on the ridge truss. It also supports loads of up to 200 kg per PA cantilever.
The total loading capacity of the main grid is 1627 kg, with a total capacity of up to 2027 kg including the PA load.
When using M290 QTVU truss, the loading capacity can be increased to 60 kg/m, while the maximum PA load can reach 300 kg per point.
Adjustable screw-jack legs with a range of 572–950 mm allow the stage to be adapted to uneven terrain. The structure is designed for wind loads of up to 30 m/s in accordance with DIN EN 17879.
The MILOS 8×6 m Stage combines high load-bearing capacity, fast assembly and a guy-wire-free design, making it a practical solution for professional events.
MILOS 8×6 m Stage with an aluminium roof designed for medium-sized events. The structure requires no guy wires thanks to the Corner Brace HD system, providing faster assembly, reduced ballast requirements and high load-bearing capacity.
