Technical Specifications
| Number of fully motorized playbacks through the fader | 10 |
| The number of encoder plays | 10 |
| Additional characteristic 1 | RGB backlighting of playbacks |
| Additional characteristic 2 | Buttons with backlighting |
MagicQ Stadium Connect
On OrderMagicQ Stadium Series
483 150 UAH
Hardware Specifications
Parameter | Value |
|---|---|
Direct DMX outputs | 4 |
Motorised playback faders | 10 |
Encoder playback faders | 10 |
Total number of playbacks | 20 (10 + 10) |
Dual crossfaders | Yes |
Attribute encoders | 4 |
Backlit keys | Yes |
Illuminated playback/encoders with RGB control | Yes |
Intensity wheel | 1 |
Network ports | 1 |
USB ports | 4 |
Audio input (sound-to-light) | Yes |
MIDI ports (in/out) | Yes |
LTC timecode (in/out) | Yes |
10Scene port | 1 |
Power input | Neutrik powerCON TRUE1, 110–240 VAC |
Maximum power consumption | 360 W |
Software Specifications
Parameter | Value |
|---|---|
DMX universes (via Art-Net/sACN/Pathport) | 64 |
Visualisation universes | 400 |
Maximum DMX channels | 204,800 |
Maximum fixtures supported | 204,800 |
Maximum cues | 5000 |
Maximum cue stacks | 2000 |
Maximum groups | 5000 |
Maximum palettes | 4096 |
Media server layers supported | 50 |
Supported OS | Windows 8.1+, macOS 12+, Linux |
MagicQ Stadium Connect is a PC-based programming interface featuring the same set of programming keys and two crossfaders as the MQ250M and MQ500M. With the ability to output 64 universes directly from Connect and preview up to 256 universes, MagicQ Stadium Connect is the ultimate solution for complete control on the go.
